Often I want to know the front center of an existing bike frame, but very few geometry charts list this value. However, geometry charts almost always list the wheelbase, bottom bracket drop, and chainstay length, and the front center can be calculated from these values. Here is the relationship: $latex FC=\left(\left(WB-(RC^2-BBD^2)^{1/2}\right)^2+BBD^2\right)^{1/2}$
Author: travisjamesallen
Internship at Paragon Machine Works
From May 14, 2018 to August 10, 2018 I interned at Paragon Machine Works, a machine shop in Richmond, CA. Paragon’s primary business is that of making parts for hand-built bicycle frame builders. Anything (and everything) that is too complicated to be manufactured by the frame builder is made by Paragon. These parts include those … Continue reading Internship at Paragon Machine Works
Solidworks Associate Certificate
Upon completion of my first mechanical engineering course at the University of Utah in the fall of 2016, I obtained an associate level certification for mechanical design from Dassault Systemes. I scored 240 out of a possible 240 points on the certification test.
SaltAir
Having recently moved to Salt Lake City for school, I found myself in town when NAHBS 2017 came around. NAHBS stands for the North American Handbuilt Bike Show, and it showcases bikes, frames, and components from folks who make their components by hand in the USA. Having grown up in a place where the weather … Continue reading SaltAir
Speaker Bracket
I drive a 2013 Regular Cab Toyota Tacoma whose OEM sound system consists of two paper-coned 5 ½” door woofers, and 2 plastic-coned 1” door tweeters, a 12.5 watt-per-channel head unit, and next to no sound or vibration damping material. This disappointing combination makes for a particularly loud and unenjoyable experience during the 12-hour, 750-mile … Continue reading Speaker Bracket
My Portfolio for Educational, Vocational, and Personal Projects
My name is Travis Allen, and I am a Mechanical Engineering student at the University of Utah Honors College. This will serve as my medium for showcasing the things I have done and created for school, work, and my own personal life. I will be adding things that I have made in the past … Continue reading My Portfolio for Educational, Vocational, and Personal Projects
